LEWDEN RCBO10-40301MC SP C 40A 30MA 10KA

The Lewden RCBO10-40301MC is a single-pole, Type C RCBO that combines overcurrent and residual-current protection in one device. It provides 40 A overcurrent protection with 30 mA earth leakage sensitivity and a 10 kA short-circuit breaking capacity, making it suitable for protecting final circuits in residential and light commercial installations.

Use this device to safeguard circuits where both overload/short-circuit protection and additional protection against electric shock are required, in consumer units and distribution boards that accept Lewden devices.

• Brand: Lewden
• Manufacturer part number: RCBO10-40301MC
• Type: RCBO (MCB + RCD combined)
• Polarity: Single pole (SP)
• Tripping curve: Type C
• Rated current: 40 A
• Residual operating current (IΔn): 30 mA
• Short-circuit breaking capacity: 10 kA
