LEWDEN RCBO10-10301MB SP B 10A 30MA 10KA

The LEWDEN RCBO10-10301MB is a compact Residual Current Breaker with Overcurrent (RCBO) designed to combine earth leakage protection with overload and short-circuit protection in a single device. It features a B-curve tripping characteristic for general-purpose circuits and is rated at 10A with 30 mA residual current sensitivity and a 10 kA breaking capacity. Suitable for single-phase applications, it is ideal for use in domestic and light commercial installations.

This single-pole RCBO fits standard DIN-rail consumer units, includes a test button for routine safety checks, and provides reliable, resettable protection for circuits such as lighting and general socket outlets where low inrush currents are expected.

• Manufacturer: LEWDEN LTD
• Model: RCBO10-10301MB
• Function: RCBO (combined RCD + MCB)
• Pole configuration: Single Pole (B-curve)
• Rated current: 10A
• Rated residual operating current: 30 mA
• Breaking capacity: 10 kA
• Application: Domestic and light commercial circuits
• Mounting: DIN-rail, for use in Lewden consumer units
• Includes test button for periodic verification
• Typical supply: 230/240 V AC, 50 Hz
