LEWDEN E10-3C20 MCB TP TYPE C 20A 10KA

The Lewden E10-3C20 is a triple‑pole (TP) miniature circuit breaker designed to protect three‑phase circuits against overloads and short circuits. With a Type C tripping characteristic and 10 kA breaking capacity, it is suitable for circuits with moderate inrush currents, such as small motors and inductive loads.

This MCB fits standard 35 mm DIN rails for quick installation in compatible consumer units and distribution boards. It provides reliable, resettable protection with a clear ON/OFF indication and robust construction for commercial and industrial applications.

• Manufacturer: Lewden
• Part number: E10-3C20
• Device type: MCB (Miniature Circuit Breaker)
• Poles: 3P (Triple‑pole)
• Tripping curve: Type C
• Rated current: 20 A
• Breaking capacity (Icn): 10 kA
• Rated voltage: 230/400 V AC, 50/60 Hz
• Mounting: 35 mm DIN rail
• Protection: Overload and short‑circuit
• Typical use: Three‑phase circuits, inductive loads, small motors
• Standards: BS EN/IEC 60898‑1
