LEWDEN E10-3C06 MCB TP TYPE C 6A 10KA

The Lewden E10-3C06 is a 3-pole (TP) miniature circuit breaker engineered to protect three-phase circuits against overload and short-circuit faults. Its Type C tripping characteristic accommodates the inrush currents typical of inductive loads such as motors while ensuring fast, reliable disconnection under fault conditions. Rated at 6 A with a 10 kA breaking capacity, it is well-suited to commercial and industrial distribution applications.

Compact and DIN-rail mountable, this MCB features a positive toggle mechanism with clear ON/OFF indication and can be reset after tripping. It is suitable for use in new installations or as a like-for-like replacement in compatible boards and enclosures.

• Manufacturer: Lewden Ltd
• Model: E10-3C06
• Device type: Miniature Circuit Breaker (MCB)
• Poles: 3 (TP)
• Trip characteristic: Type C
• Rated current: 6 A
• Breaking capacity: 10 kA
• Protection: Overload and short-circuit
• Application: Three-phase circuits and general inductive/mixed loads
• Mounting: 35 mm DIN rail
• Operation: Toggle, resettable after trip
