LEWDEN E10-1C32 MCB SP TYPE C 32A 10KA

The Lewden E10-1C32 is a single-pole miniature circuit breaker designed to protect circuits against overloads and short-circuits. Its Type C trip characteristic is suitable for circuits with moderate inrush currents, such as small motors and lighting. With a 10 kA breaking capacity and 32 A rated current, it provides reliable protection for residential and light commercial installations. It mounts on a standard DIN rail and is intended for use in Lewden consumer units and distribution boards.

• Brand: Lewden
• Series: E10
• Manufacturer part number: E10-1C32
• SKU/Reference: lewden-e10-1c32-mcb-sp-type-c-32a-10ka-211546
• Device type: MCB (Miniature Circuit Breaker)
• Poles: 1P (single-pole)
• Trip curve: Type C
• Rated current: 32 A
• Breaking capacity: 10 kA
• Voltage rating: 230/400 V AC
• Standard: BS EN 60898-1
• Mounting: 35 mm DIN rail (1 module width)
• Applications: general circuit protection; circuits with moderate inrush (e.g., small motors, lighting)
• Typical use: residential and light commercial distribution boards
