HAGER ADA316G 1M 1P 6KA B-16A 30MA AC CL

The Hager ADA316G is a compact RCBO that combines overcurrent and earth leakage protection in a single 1-module device. Designed for space-saving installation in consumer units, it provides reliable protection for general-purpose circuits with B-curve tripping and 30 mA residual current sensitivity. Suitable for 230/240 V AC applications in domestic and light commercial settings.

• Brand: Hager
• Model: ADA316G
• Type: RCBO (combined RCD + MCB)
• Poles: 1P
• Module width: 1M
• Rated current: 16 A
• Tripping curve: B
• Breaking capacity: 6 kA
• Residual current rating: 30 mA
• Residual current type: AC (Class AC)
• Voltage: 230/240 V AC
• Mounting: DIN-rail, suitable for Hager consumer units
• Application: General circuit protection in domestic and light commercial installations
