HAGER ADA310G 1M 1P 6KA B-10A 30MA AC CL

The Hager ADA310G is a compact single-module RCBO that combines overcurrent and earth leakage protection for single-phase final circuits. With a Type B tripping characteristic, 6 kA breaking capacity, and 30 mA AC residual protection, it is suitable for general-purpose circuits such as lighting and sockets in residential and light commercial installations. Designed for DIN rail mounting and Hager consumer units, it helps save space while providing reliable protection.

• Brand: Hager
• Manufacturer: Hager Limited
• Part number: ADA310G
• Device type: RCBO (Residual Current Circuit Breaker with Overcurrent protection)
• Poles / module width: 1P, 1M (single module)
• Rated current: 10 A
• Tripping characteristic: Type B
• Breaking capacity: 6 kA
• Rated residual operating current: 30 mA
• RCD type: AC
• Voltage: 230 V AC single-phase
• Mounting: DIN rail
• Application: final circuit protection for sockets and lighting
• Compatibility: designed for Hager consumer units
