FUSEBOX AFDD 16A 30MA 2P AFDD061630B

The FuseBox AFDD 16A 30mA 2P (AFDD061630B) is a two-pole arc fault detection device with integrated overcurrent and residual current protection for single-phase circuits. It detects dangerous series and parallel arc faults and trips to reduce fire risk, while also providing MCB and RCD functions in one compact unit.

Rated at 16A with 30mA residual sensitivity and a B-curve tripping characteristic, this device is suitable for protecting final circuits in domestic and similar installations. It mounts on a standard DIN rail and is designed for use in FuseBox consumer units and compatible boards.

• Brand: FuseBox
• Product code: AFDD061630B
• Function: AFDD with integrated overcurrent and residual current protection
• Poles: 2P (switches live and neutral)
• Rated current: 16A
• Residual operating current: 30mA
• Tripping curve: B
• Short-circuit capacity: 6kA
• Voltage: 230V AC, 50Hz
• Mounting: DIN rail
• Application: Final circuit protection with arc fault, overload, short-circuit, and earth leakage protection
• Test button: Yes
