FUSEBOX 10A B CURVE MCB 6KA 1P MT06B101

The FuseBox 10A Type B MCB is a single-pole miniature circuit breaker designed to protect circuits against overloads and short circuits in domestic and light commercial installations. With a 6kA breaking capacity and a Type B tripping characteristic, it is suitable for circuits with low inrush currents such as lighting and general-purpose final circuits.

Compact and DIN-rail mountable, this 1-module device is ideal for use in FuseBox consumer units and other compatible enclosures. The MT06B101 model offers reliable, quick disconnection to help keep wiring and connected equipment safe.

• Brand: FuseBox
• Model: MT06B101
• Current rating: 10A
• Tripping curve: Type B
• Poles: 1P (single pole)
• Breaking capacity: 6kA
• Protection: Overload and short-circuit
• Mounting: DIN rail, 1 module width
• Typical use: Lighting and general circuits with low inrush current
• Voltage: 230/400V AC (typical MCB rating)
• Standard: BS EN 60898-1
