CUDIS MC306D 6A TP 6KA TYPE D MCB

The CUDIS MC306D is a 6A triple pole miniature circuit breaker designed for three-phase circuits that require Type D tripping characteristics. With a 6kA short-circuit breaking capacity, it provides dependable overload and fault protection for circuits with high inrush currents such as motors and transformers. It mounts on standard 35 mm DIN rail and is suitable for use in modular distribution boards. Manufactured by Cudis Limited and compliant with BS EN 60898-1, it offers reliable protection and straightforward operation for commercial and light industrial applications.

• Manufacturer: Cudis Limited
• Model: MC306D
• Device type: MCB (Miniature Circuit Breaker)
• Poles: Triple Pole (3P)
• Rated current: 6A
• Trip curve: Type D (for high inrush loads)
• Breaking capacity: 6kA
• Rated voltage: 230/400V AC, 50/60Hz
• Mounting: 35mm DIN rail (EN 60715)
• Standard compliance: BS EN 60898-1
• Application: Protection of three-phase circuits in commercial and light industrial installations
