CUDIS MC240D 40A DP TYPE D MCB

The CUDIS MC240D is a 40A double pole Type D miniature circuit breaker designed to protect circuits with high inrush currents. It provides reliable overload and short-circuit protection, with a Type D trip characteristic suited to equipment such as motors, pumps, compressors, and transformers. The double-pole design isolates both conductors in single-phase applications, enhancing safety during maintenance and fault conditions. Compact and DIN-rail mountable, it’s a practical choice for distribution boards where robust protection and positive isolation are required.

• Brand: CUDIS Limited
• Model: MC240D
• Rated current: 40A
• Poles: Double Pole (2P)
• Trip curve: Type D (instantaneous trip typically 10–20x In)
• Protection: Overload and short-circuit
• Operation: Resettable with ON/OFF toggle
• Mounting: Standard 35 mm DIN rail
• Typical uses: High inrush loads (motors, pumps, compressors, transformers, welding equipment)
• Note: Ensure compatibility with your distribution board and local wiring regulations
