CUDIS MC132B 32A SP 6KA TYPE B MCB

The CUDIS MC132B is a single-pole miniature circuit breaker (MCB) designed to protect final circuits against overload and short-circuit faults. With a 32 A rating, a Type B tripping characteristic for general-purpose loads with low to moderate inrush currents, and a 6 kA breaking capacity, it is suitable for domestic and light commercial installations.

It installs in consumer units and distribution boards, mounts on standard DIN rail, and can be manually switched to isolate and reset a circuit after a trip.

• Brand: CUDIS (CUDIS LIMITED)
• Product code: MC132B
• Device type: Miniature Circuit Breaker (MCB)
• Poles: Single Pole (SP)
• Rated current: 32 A
• Tripping characteristic: Type B
• Short-circuit breaking capacity: 6 kA
• Mounting: DIN rail
• Application: Overload and short-circuit protection for final circuits
