CUDIS - 20A 10KA 30MA RCBO TYPE B

This 20A RCBO from Cudis combines overcurrent and earth leakage protection in a single device, providing reliable protection for individual final circuits in domestic and light commercial installations.

It offers a 10kA short-circuit breaking capacity, 30mA residual current sensitivity for additional protection against electric shock, and a Type B tripping characteristic suitable for general-purpose circuits with low inrush currents such as lighting and socket outlets.

Use only in compatible distribution boards and enclosures as specified by the manufacturer. Installation and testing should be carried out by a qualified electrician.

• Brand: CUDIS LIMITED
• Device type: RCBO (Residual Current Breaker with Overcurrent)
• Rated current: 20A
• Residual current sensitivity: 30mA
• Rated short-circuit capacity: 10kA
• Trip characteristic: Type B
• Functions: Overload, short-circuit, and earth leakage protection
• Typical use: General-purpose final circuits with low inrush loads
• Reference: cudis-20a-10ka-30ma-rcbo-type-b-464086
