CUDIS- 16A 10KA 30MA RCBO TYPE C

This RCBO from CUDIS combines miniature circuit breaker and residual current protection in a single device, providing reliable protection against overload, short-circuit and earth leakage faults. With a 16A rating, 10kA breaking capacity and a Type C tripping characteristic, it is suitable for circuits with moderate inrush currents such as lighting and small motor loads. The 30mA residual current sensitivity offers additional protection for people and property in domestic and light commercial installations.

• Brand: CUDIS
• Device type: RCBO (MCB + RCD combined)
• Rated current: 16A
• Tripping characteristic: Type C
• Residual operating current (RCD): 30mA
• Breaking capacity: 10kA
• Voltage/frequency: 230V AC, 50Hz
• Protection functions: overload, short-circuit, earth leakage
• Mounting: DIN rail for consumer units/distribution boards
• Application: domestic and light commercial final circuits
