16A TYPE A CURVE C 1P+SWN BIDRCBO PD4316

This Deta PD4316 BIDRCBO provides combined overcurrent and earth leakage protection for single-phase circuits. Rated at 16A, it integrates MCB and RCD functions in one device to protect against overloads, short circuits, and residual current faults. The Type A RCD element detects AC and pulsating DC residual currents from modern electronic loads, while the Curve C tripping characteristic suits general-purpose circuits with moderate inrush currents. Its 1P+SWN configuration switches and isolates both line and neutral for added safety in residential and light commercial installations.

• Brand: Deta Electrical Co. Ltd
• Model: PD4316
• Type: RCBO (Residual Current Breaker with Overcurrent protection)
• Rated current: 16A
• RCD type: Type A (detects AC and pulsating DC)
li>Tripping characteristic: Curve C
• Poles: 1P + Switched Neutral (1P+SWN)
• Function: Combined overload, short-circuit, and earth leakage protection
• Mounting: DIN rail for consumer units/distribution boards
• Typical applications: general circuits with moderate inrush (e.g., lighting, socket outlets, small motors, and electronic loads)
