1" BSP MALE X 28MM COMPRESSION ADAPTER

The SOLFEX LTD 1" BSP Male x 28 mm Compression Adapter is a robust brass fitting designed to join components with a 1" BSP female thread to 28 mm copper tube. It provides a secure, demountable transition between threaded equipment such as manifolds, valves, or pumps and 28 mm pipework, without the need for soldering.

The BSP male end connects to standard British Standard Pipe fittings, while the compression end tightens onto 28 mm tube using an olive and nut to create a reliable mechanical seal. Suitable for use in domestic and commercial plumbing and heating circuits with water-based media. For plastic barrier pipe, use the correct pipe insert as per the pipe manufacturer’s guidance.

• Connection 1: 1" BSP male thread
• Connection 2: 28 mm compression for copper tube
• Material: Brass
• Application: Heating and plumbing systems; manifolds, pumps, valves and general pipe transitions
• Installation: Use PTFE tape or suitable thread sealant on the BSP male thread as required
• Joint type: Demountable compression connection (no soldering required)
• Compatibility: 28 mm copper tube; plastic pipe with the correct insert (check pipe maker’s instructions)
• Brand: SOLFEX LTD
